Tools & Evaluation
|
Great products need sophisticated tools to make them happen. Find here a broad selection of dedicated tools to realize your own ideas.
Sound Development Kits
| Name | Description | Content | Compatible IC |
| 5000-SDK |
Development tools for custom sounds |
5000-SDK box + Install CDROM + Sound editor and compiler tools. |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
| Dream-Piano-5000 |
Dream-Piano-5000 package is a sound library of professional Piano and Keyboard sounds. They were specially designed to be used in Digital Pianos and other musical instrument products using Dream® SAM5000 series of proprietary DSPs. |
License Key |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
| Dream-Piano16 |
Dream-Piano16 package is a sound library of professional Piano and Keyboard sounds (subset of Dream Piano-5000 sound package). They were specially designed to be used in digital Pianos and other musical instrument products using Dream® SAM5000 series of proprietary DSPs. |
License Key |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
| Dream-AcousticDrums-5000 |
Dream-AcousticDrums-5000 package is a sound library of professional acoustic drum sounds. They were specially designed to be used in digital drums and other musical instruments using our SAM5000 series of proprietary DSPs. Dream-AcousticDrums-5000 contains more than 240 carefully recorded and edited drum sounds and variations. |
License Key |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
| Dream-CleanDrum16 |
Dream-CleanDrum16 package is a sound library of professional acoustic and electronic drum sounds. They were specially designed to be used in digital drums and other musical instruments using our SAM5000 sreies of proprietary DSPs. Dream-CleanDrum16 contains more than 100 carefully recorded and edited drum sounds and variations (subset of Dream CleanDrum64-5000 sound package). |
License Key |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
| Dream-CleanWave-5000 |
Dream-CleanWave-5000 package is a license free sound library of General MIDI sounds for 5000-SDK. They were designed to be used in MIDI sound module / Karaoke players etc. using our SAM5000 sreies of proprietary DSPs. Dream-CleanWave-5000 sound package contains more than 300 carefully recorded and edited sounds of various instruments and drumsets. |
(free download) |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
Product Development Kits
| Name | Description | Content | Compatible IC |
| 5916PIA2-DK (PDK) |
High range Digital Piano Development kit for SAM5916 |
5916PIA-DK board + Front Panel + 5000DBG-IF interface board (Software via download link) |
SAM5916B |
| 5704PIA-DK (PDK) |
Development kit for Piano/Keyboards applications with SAM570B |
5704PIA-DK board + Front Panel + 5000DBG-IF interface board (Software via download) |
SAM5704B |
| 5000 Series Firmware Development |
All SAM5000 Series EK & DK Boards are shipped with 5000DBG-IF programming & debug interface board and can be used for firmware development purpose. |
5000 Series Evaluation Board + 5000DBG-IF interface board (Software via download link) |
SAM5716B SAM5708B SAM5704B SAM5504B |
Evaluation Boards & Reference Designs
| Name | Description | Compatible IC |
| 5916PIA2-DK | 256-voice, High resolution Piano evaluation and development kit including 5916PIA2-DK engine board and 5000FP-DK front panel, up to 32Gbit Nand Flash (default:16Gbit), 64Mbit SDRAM, 8Mbit Dataflash, direct connection to a 3-contact FATAR type keyboard (max 88 keys), 2 x audio DAC stereo 24bit (DR: 120dB, THD+N: -100dB), 1x audio ADC (24bit, DR:110dB, S/(N+D):96dB), connectors to control panel with COG graphic display 128*64, 21 switches, 21 LEDs, USB Host and USB Device. Ethernet. |
SAM5916B |
| 5716-DK |
Development and reference board dedicated to high quality sound module and effect devices, with 2-channel Audio In (ADC 24bit, DR=110dB, S/(N+D)=96dB), 4 Audio Out (2 DAC 24bit, DR=106dB, THD+N=-94dB), up to 16Gbit Nand Flash (default: 4Gbit), 64Mbit SDRAM, USB high speed device, MIDI In/Out, optical S/PDIF In/Out. |
SAM5716B |
| 5716-EK | Stand alone high quality sound module demo board with 2-channel Out, 1 Audio DAC 24bit (DR = 106dB, THD+N = -94dB), up to 16Gbit Nand Flash (default: 4Gbit), 64Mbit SDRAM, USB high speed device, MIDI In. |
SAM5716B |
| 5808-DK | Development and reference board dedicated to digital piano, keyboard and digital drums, with 2-channel Audio In (ADC 24bit, DR:110dB, S/(N+D):96dB), 4 Audio Out (2 DAC 24bit, DR:106dB, THD+N:-94dB), 16Gbit NAND Flash, 64Mbit SDRAM, USB high speed device, MIDI In/Out, Ethernet, optical S/PDIF Out. |
SAM5808B |
| 5704PIA-DK | 81-voice Piano evaluation and development kit including engine board and front panel, 2x256Mbit QNor Flash, 4Mbit Dataflash®, direct connection to a FATAR type keyboard (max 88 keys), connector to control panel with 25 switches, 28 LEDs and 3-digit LED display, SD Card socket, USB high speed device, Audio CODEC (ADC: S/N=103dB, S/N+D=91dB | DAC: S/N=106dB, S/N+D=90dB). |
SAM5704B |
| 5704FX-EK |
Evaluation board with 2-channel In and 2-channel Out, Audio CODEC (ADC: S/N=103dB, S/N+D=91dB | DAC: S/N=106dB, S/(N+D):96dB), 64Mbit SDRAM, 2Mbit SPI Flash, USB High Speed Device, connection to dedicated Front Panel. |
SAM5704B |
| 5504FX-EK | Stand-alone lowest cost digital Audio processing/USB Audio IF/Effects module |
SAM5504B |
| 5504-DK |
Low cost USB / MIDI Sound module with AUX/Mike inputs (5504-FW_MICFX firmware). The 5504-DK is a stand-alone evaluation and development board based on SAM5504 and dedicated to low cost applications. Hardware includes 2 Audio DAC (24bit, DR:106dB, THD+N: -94dB), 1 Audio ADC (24bit, DR:110dB, S/(N+D):96dB), 512 Mbit Quad-SPI Flash memory, USB High Speed Device port, Optical SPDIF In and Out, Midi In/Out, Multi-purpose connector for Audio extension or Scanning interface or Versatile IOs. |
SAM5504B |
| 5504-EK | Evaluation kit for lowest cost MIDI/USB sound module. The 5504-EK is a stand-alone evaluation board based on the SAM5504 dedicated to low cost applications. Hardware includes 1 Audio DAC (24bit, DR:106dB, THD+N: -94dB), 256Mbit Quad-SPI Flash memory, USB High Speed Device port, 2 FFC connectors for multi purpose (serial MIDI, 61-key velocity keyboard, front panel) |
SAM5504B |
| 2635-EK | Stand alone evaluation board dedicated to low cost and low power applications. Includes 256Mbit Flash memory, optionally can be upgraded to 512Mbit |
SAM2635 |
| 2695-EK | The SAM2695- EK demonstrates a typical low cost and low power application of SAM2695 (Single Chip Synthesizer with Effects) |
SAM2695 |
Programming Tools
| Name | Description | Compatible IC |
| USB-Prog |
Kit for programming built-in eFuse of SAM5000 series, and for firmware and sound bank pogramming in external Flash devices (incircuit, via SAM5000 IC debug interface). Content: 5000DBG-IF interface ("ProgSam" software via download) |
SAM5916B SAM5716B SAM5808B SAM5708B SAM5704B SAM5504B |
